- 施耐德防爆断路器10A 20A 25A 32A 100A防爆断路器
详细信息
加工定制:是 额定电流:220 A 壳体防护等级:IP65 外形尺寸:定制 mm 外壳材质:铝合金 型号:100A 施耐德防爆断路器10A 20A 25A 32A 100A防爆断路器适用范围
1、爆炸性气体混合物危险场所:1区、2区。
2、爆炸性气体混合物ⅡA、ⅡB、ⅡC。
3、温度组别:T1~T6。
4、防爆标志:ExdⅡBT6、ExdeⅡBT5、*ExdⅡCT5。
注:要求ⅡC级请注明。
系列防爆断路器 防爆负荷开关 防爆倒顺开关 防爆开关
施耐德防爆断路器10A 20A 25A 32A 100A防爆断路器技术参数
防爆标志:ExdeIIBT4/T5/T6、ExdeIICT4/T5/T6、DIP A20 TA,T4/T5/T6;
额定电压:AC220/380V, 非标准电压:12V/24V/36V/127V/660V;
开关电流:10A—800A;
防护等级:IP54/IP55/IP65;
螺纹规格:DN15-DN100/G1/2-G4寸
引入线规格:直径6mm-80mm;引出线规格:直径6mm-80mm;
引入引出方向:上进上出,下进下出(可按客户要求不受限制)
施耐德防爆断路器10A 20A 25A 32A 100A防爆断路器产品特点
1. 本产品外壳采用铝合金压铸成型,表面经高速抛丸后粉末静电喷塑,外形美观;
2. 本产品为复合型防爆结构,开关箱采用隔爆型结构,接线箱采用增安型结构;
3. 采用模块化设计,各种回路可以自由组合;
4. 内装高分断小型漏电断路器或塑壳式漏电断路器,通过操作防爆客体外的手柄而实现分合;
5. 本产品全面推出新型优化的设计方案及操作机构,结构紧凑合理、通用性强、操作灵活方便、手感好;
6. 具有过载、短路、缺相、漏电保护功能;
7. 所有紧固件均采用抗强腐蚀的304不锈钢材质;
8. 布线方式,钢管或电缆、防爆软管均可;
9. 可根据用户要求特殊定制;
施耐德防爆断路器10A 20A 25A 32A 100A防爆断路器
First, the scope of application
1, explosive gas mixture dangerous places: 1 area, 2 area.
2, explosive gas mixture II B, II A, II C.
3, temperature group: T1 ~ T6.
4, explosion-proof mark: Exd II Exde, BT5 II *Exd, BT6 II CT5.
Note: Please specify the class II C.
Explosion proof load switch of series explosion-proof circuit breaker
Two, technical parameters
Explosion proof mark: ExdeIIBT4/T5/T6, ExdeIICT4/T5/T6, A20 TA DIP, T4/T5/T6;
Rated voltage: AC220/380V, non - standard voltage: 12V/24V/36V/127V/660V;
Switching current: 800A - 10A;
Protection level: IP54/IP55/IP65;
Thread specification: DN15-DN100/G1/2-G4 inch
Introduction of line specifications: diameter 6mm-80mm; lead outlet specifications: diameter 6mm-80mm;
Lead in the direction of the introduction: upward progress, under the (can be according to customer requirements are not limited)
Three, product features
1 the product shell with Aluminum Alloy die-casting molding, the surface by high speed shot after the powder electrostatic spray, beautiful appearance;
2 this product is a compound type explosion-proof structure, the switch box adopts the explosion proof structure, and the connection box adopts the structure of increasing the safety;施耐德防爆断路器10A 20A 25A 32A 100A防爆断路器
3 modular design, a variety of circuits can be freely combined;
4. Installed with high broken small leakage circuit breaker or molded case leakage circuit breaker, through the handle of the operation in vitro explosion-proof passenger and realize the and points.
5 this product launches the new optimized design plan and the operating mechanism, the structure is compact and reasonable, the versatility is strong, the operation is flexible and convenient, the feeling is good;
6 with overload, short circuit, lack of phase, leakage protection function;
7 all fasteners are made of 304 stainless steel with strong corrosion resistance;
8 wiring way, steel pipe or cable, explosion-proof hose can be;
9 can be customized according to user requirements;
施耐德防爆断路器10A 20A 25A 32A 100A防爆断路器注意事项
1。安装使用产品前应检查铭牌上的技术数据与使用情况是否相符;
2。安装及维修前必须切断前级电源;
3。进、出线电缆穿过橡胶密封圈,须用垫圈及压紧螺母压紧,保证密封及电缆不得松动;
4。密封圈在使用过程中出现腐蚀、脆裂、变形、发粘或硬度变化超过出厂时的20%应及时向厂家进行选购并更换,以确保防爆性能可靠;
5。维护拆卸时注意隔爆面不得磕碰、划伤、腐蚀,并定期涂204-1防锈油;
6。配电箱在使用过程中要定期检查,以保证其良好运行;
7。非*人员严禁开盖维修、检查。
施耐德防爆断路器10A 20A 25A 32A 100A防爆断路器定购流程
一.说明产品的规格,参数与数量或致电: QQ:---
二.我方在参考客户供提供的相关资料给予定制合适的订购方案
三.双方同意,传真形式签定销售合同
四.用户付款后,方可生产或需打订金需付30%.在产品做好发货当天,请于将余款补齐即可,方可发货.
五.合同签订,双方需盖公司公章,予以证明,合同起效,双方严格履行合同.
六.产品质保一年,如无人为条件,我公司免费保证一年维修与维护.
